P3™ Truck-Mounted Patcher with DuraPatcher™ Technology

  • Simplify patching operation – Just add rock and emulsion with this self-contained patching machine
  • Maximizes your budget by never having to patch the same pothole twice
  • Faster and simpler patching process that limits public disruption
  • Universal design mounts to most truck chassis and is ideal for tight-turn radii and low clearance residential streets
  • Heated emulsion tank provides enough product to apply over 10 tons of patch material
  • Onboard heat allows you to create a permanent patch in almost any weather
  • Ergonomic, no-stress boom easily covers an 18-foot working radius
  • Specially designed Vent-Flo™ nozzle that thoroughly coats the aggregate with emulsion, ensuring a permanent patch
  • Powerful blower and DuraPatcher venturi system can reliably delivers aggregate up to 2.5” in diameter
  • Virtually no moving parts in the delivery system which lowers pavement maintenance costs
Emulsion Capacity: 250 Gallons
Aggregate Capacity: 6 Yards
Engine: 74HP IT4 Diesel
Heating Method (overnight): Electric Blanket
Heat Rating: 2 x 1500 Watts
Tank Insulation: R 15
Blower: 450 CFM at 1500 RPM, 10 PSI
Clean Out: 15 Gallons
Fuel Capacity: 18 Gallons
Construction: 10” Channel Main Frame
Drain Valve: 3”
Temperature Gauge: 5″
Dimensions w/o Truck (l x w x h): 241” x 92” x 76”
Shipping Weight: 9,550 lb.
Warranty: One Year

Due to continuous improvement, specifications are subject to change without notice.
